PC2 Pro Handheld Drone Detection-Jamming-Spoofing Device

PC2 Pro Handheld Drone Detection-Jamming-Spoofing Device

PC2 Pro is a handheld integrated counter-drone device combining detection, jamming, and spoofing.Using spectrum sensing, RF jamming, and navigation spoofing, it provides drone detection and warning,identity recognition, direction finding, positioning,directional control and spoofing.With a real-time display, multi-device networking,and location reporting, PC2 Pro meets the requirements for the intelligent, unified scheduling and management of low-altitude defense zones.

Features

Drone & Pilot Positioning
Real-time display of both drone and pilot locations
All-in-One Functions
Integrates detection, jamming, and deception in one device
Comprehen sive Recognition
Identifies common commercial drones (DJI, Autel) and most non-commer cial types, including FPV and WiFi drones
Flexible Countermea sures
Directional jamming with selectable “repulsion” or “spoofing” modes
Visual Direction Finding
Provides target direction on an intuitive graphical interface
Networked Management
Networking with control platform for real-time remote monitoring the data of device information, status and detection control
Long Battery Life
Detachable battery supports extended missions
Portable & Ready
Lightweight, single-operator carry, immediate deployment

Specifications-Detection

Working mode
Passive detection
Detection frequency band
100MHz~6GHz
Detection radius
500m~3000m(Varies with environment and model)
Number of detection targets
≥10
Battery life
~5h

Specifications-Jamming

Jamming frequency band
Drone video transmission Remote control frequency band
Jamming range
500~1500m(Varies with environment and model)
Spoofing frequency band
GPS、GLONASS L1
Spoofing radius
500~1000m(Varies with environment and model)
Battery life
~0.5h
Size
(850mm*382mm*95mm)±5mm
Weight
~8.5kg
